New
1970
EQUIPPED WITH: Hydraulic Profile Grinding Wheel
Truing, Hydraulic Profile Regulating Wheel Truing.
CATALOGUE SPECIFICATIONS:
Work Diameter Capacity Maximum (With New
Wheel)........ 6"
Work Diameter Capacity
Nominal......................... 1/2" to 3"
Grinding Wheel Diameter,
Maximum....................... 24"
Grinding Wheel Diameter,
Minimum....................... 16"
Grinding Wheel Width,
Maximum.......................... 20"
Grinding Wheel Width,
Minimum.......................... 1"
Grinding Wheel Hole
Diameter........................... 12"
Regulating Wheel Diameter,
Maximum..................... 14"
Regulating Wheel Diameter,
Minimum..................... 10.25"
Regulating Wheel Width,
Maximum........................ 20"
Regulating Wheel Width,
Minimum........................ 1"
Regulating Wheel Hole
Diameter......................... 6"
Regulating Wheel Speeds
(Variable)..................... 11 - 300 RPM
Grinding Wheel
Motor................................... 40 HP
Regulating Wheel
Motor................................. 2 HP
Hydraulic System
Motor................................. 2 HP
Electrics..............................................
230/460/3/60
Approximate Machine
Dimensions......................... 114" x 158"
Approximate Machine
Height............................. 96"
Approximate Machine
Weight............................. 28,000 LBS
