Power Arm Elevation, Power Column Clamp/Unclamp, Power Head Rapid
Traverse, Depth Control, Tapping, Box Table, Coolant System.



CATALOGUE SPECIFICATIONS:

 Arm Length............................................ 5'
Column Diameter....................................... 13"
Working Surface of Base (T-Slotted)................... 3'2" x 5'5"
Vertical Spindle Travel in Head....................... 14-1/2"
Vertical Travel of Horiz Arm on Column................ 49-1/2"
Horizontal Head Travel on Arm......................... 50-1/2"
Drills to Center of Circle on Base.................... 121"
Distance Spindle to Base, Maximum..................... 54-1/2"
Distance Spindle to Base, Minimum..................... 12-1/2"
Face of Column to Spindle, Maximum.................... 60-1/2"
Face of Column to Spindle, Minimum.................... 10"
Spindle Taper......................................... #5 MT
Spindle Speeds (12) Range............................. 30 to 1500 RPM
Spindle Feeds (9) Range.............................. .003 to .040 IPR
Motor................................................. 7.5 HP
Height of Base........................................ 8"
Approximate Machine Dimensions........................ 37" x 127"
Approximate Machine Height ........................... 112"
Approximate Machine Weight............................ 9,600 LBS



CONDITION: Machine appears to be in Very Good Condition !
