273A HEALD FOR SALE UNIVERSAL INTERNAL GRINDER

273A HEALD UNIVERSAL
INTERNAL GRINDER
Stock Number K13255
|

 |
ACTUAL PHOTOS
|
273A HEALD UNIVERSAL
INTERNAL GRINDER
Model 273A, New 1976, S/N 47486
Stock# K13255
Facing Attachment, Workhead
Positioning Stop With Indicator, Manual
Positioning Workhead Slide, 9" Magnetic Chuck, Rough and Finish Cycles
with Spark-Out, 11,000 RPM Redhead Spindle, Variable Speed Workhead,
Coolant
System.
CATALOGUE SPECIFICATIONS:
Swing Over Table,
Maximum.............................. 24-1/2"
Swing Inside Coolant Splash Guard, Maximum............. 20"
Grinding Stroke, Maximum............................... 16"
Workhead Cross Travel.................................. 17-1/2"
Workhead Longitudinal Adjustment on Bridge............. 12"
Wheelhead Slide Longitudinal Travel.................... 20"
Wheelhead Slide Cross Travel........................... 1-1/2"
Workhead Flange to Wheelhead Slide..................... 0" to 30"
Table Longitudinal Feeds, Variable..................... 0 to 18 FPM
Angular Adjustment of Workhead......................... 90 Degrees
Workhead Speeds, Variable.............................. 0 to 500 RPM
Wheelhead Motor, Horsepower............................ 5 HP
Workhead Motor, Horsepower............................. 1-1/2 HP
Hydraulic Motor, Horsepower............................ 1/2 HP
Coolant Motor, Horsepower.............................. 1/4 HP
Electrics.............................................. 220/440/3/60
Approximate Machine Dimensions......................... 91"x96"
Approximate Machine Height............................. 75"
Approximate Machine Weight............................. 6,200 LBS
CONDITION: Appears to be in
Very Good Condition !
|
 |

|
