EQUIPPED WITH:



OSP 700M CNC Control, RS 232 Port, 4th Axis Drive and Prewire, Cycle
Time Reduction, Rigid Tap, VAC Type A, Helical Cut, Work Coordinate
Change, Exact Stop, Inch Metric Programming, Rev/Min Feed, 1/10000
Angle, Additional Math Function, Sub Programs, Pendent MPG, 20 Position
Automatic Tool Changer, Spindle Chiller Full Enclosure, Chip Conveyor,
Coolant System.



CATALOGUE SPECIFICATIONS:



Table Working Surface............................. 51.18" x 22.05"
Table Load Capacity............................... 1,500 LBS
Longitudinal Travel (X-Axis)...................... 41.3"
Cross Travel (Y-Axis)............................. 22"
Vertical Travel (Z-Axis).......................... 17.72"
Rapid Traverse Rate (X and Y Axes)................ 1181 IPM
Rapid Traverse Rate (Z Axis)...................... 945 IPM
Spindle Face to Table Surface..................... 7.8" - 28.6"
Tool Storage Capacity............................. 20
Spindle Speeds Range.............................. 50-6000 RPM
Spindle Taper..................................... CAT-50
Approximate Machine Dimensions.................... 114" x 114"
Approximate Machine Height........................ 104"
Approximate Machine Weight........................ 14,500 LBS



CONDITION: Machine Appears to be in Excellent Condition!
